Specifications

• Mfr Part Number: S2900-48T4X-2AC
• 48-Port Gigabit RJ45
• 4-Port 10G/GE SFP+
• Gigabit Interface:RJ45: 48
• 10GE/GE Interface: 4
• Console(RJ45): 1
• Backplane(Gbps): 216
• Forwarding rate (Mpps with 64 bytes): 162
• Power consumption:
  • no-load: < 25W
  • full-load: < 48W
• Power supply: 50w
• Total output BTU (1000BTU/H=293W): 163.82
• Fan number: 2
• Noise 25C(dBA): 45
• MTBF(H): >200,000
• Forwarding mode: Store-forward
• Flash (MB): 16
• DRAM (MB): 512
• MAC: 32K
• Buffer size(MB): 1.5
• Interface vlan: 64
• Routing table: 512
• Jumbo frame: 9k
• Features:
  • VLAN: 4K Active VLAN, QinQ and Selective QinQ, GVRP, Private VLAN, Voice VLAN
  • Spanning Tree:
    • 802.1D (STP), 802.1W (RSTP) and 802.1S (MSTP)
    • BPDU guard, root guard and loopback guard
  • Multicast: IGMP v1/v2/v3, IGMP Snooping, IGMP Fast Leave, MVR, IGMP filter
  • IP:
    • Static route
    • IPv4/v6 dual stack
  • IPV6:
    • ICMPv6, DHCPv6, ACLv6 and Ipv6 Telnet
    • IPv6 neighbor discovery, Path MTU discovery
    • MLD V1, MLD snooping IPv6 Static Routing, RIPng, OSPFv3
    • Manual tunnel, ISATAP tunnel, 6 to 4 tunnel
  • Certification: CE, FCC, ROHS
  • QoS:CAR, HQoS, MAC/IP/TCP/UDP/ VLAN/COS/DSCP/TOS based QoS, 802.1P/DSCP priority re- labeling, SP, WRR, and SP+WRR, Tail-Drop, WRED, flow monitoring and traffic shaping
  • Security:
    • Port isolation, Port security, and IP+MAC+port binding, MAC sticky
    • DHCP Snooping and option 82, DAI and IP source guard, PPPoE+
    • IEEE 802.1x, Radius and BDTacacs+
    • L2/L3/L4 ACL flow identification and filtrationAnti-attack from DDoS, TCPs SYN Flood, UDP Flood, etc. Broadcast/multicast/unknown unicast storm-control
    • MD5, SHA-256, RSA-1024, AES256, etc.
  • DHCP:
    • DHCP server/relay/client
    • DHCP snooping/option82
  • Reliability:
    • Static/LACP link aggregation, Interface backup
    • EAPS and ERPS
    • ISSU uninterrupted system upgrade
    • BVSS, ups to 16-units per stack
    • VRRP
    • UDLD
  • Management:
    • Console, Telnet, SSH v1/2, HTTP, HTTPS, SNMP v1/v2/v3, RMON
    • TFTP, FTP, SFTP
    • NTP
    • ZTP
    • SPAN, RSPAN
    • Dying gasp
  • Environment:
    • Operating temperature/ humidity: 0C -50C,10%-90% non-condensing
    • Storage temperature/humidity: -20C -70C, 5%-95% non-condensing
  • Accessories: Power cord, rackmount kits, console cable
• Chassis:
  • Dimensions (WxDxH)(mm): 440x280x44
  • Weight (KG)(empty): 4.3
• Package:
  • Dimensions (WxDxH)(mm): 576x448x94
  • Weight(KG): 5.5
