Flexible Configuration and Management of Disk Arrays
Across-Platform File Management and Sharing
Enhance the Safety of your Data with a Superior File System
Virtualization Storage Solutions
Multiple Backup Solutions
Striving to Satisfy Small and Medium-sized Businesses
Processor:
Processor Model:Intel Celeron N5105/N5095
Processor Architecture: X.86 64-bit
Processor Frequency: Quad Core 2.0 GHz (Max burst up to 2.9 GHz)
Hardware Encryption Engine: Yes
Hardware Transcoding Engine:H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60
Memory:
System Memory:8GB
Pre-installed Memory module: 1
Total Memory Slot Number: 2 (SO-DIMM)
Maximum Supported Memory:32 GB (16 GB + 16 GB)
Note: TerraMaster reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance
Storage:
Disk Slot Number:9
Compatible Drive types:3.5" SATA HDD,2.5" SATA HDD,2.5" SATA SSD
Maximum Internal Raw Storage Capacity:180TB (20TB x 9) (Capacity may vary by RAID types)
Max Single Volume:108TB
Drive Hot Swap:Yes
Note: - Hard drive vendors will release their latest models of hard drives, and Maximum internal raw storage capacity may be adjusted accordingly
- The maximum single volume size is not directly related to the maximum raw capacity
File System:
Internal Drive:EXT4, BTRFS
External Drive:EXT3, EXT4, NTFS, FAT32, HFS+
External Ports:
2 x RJ-45 2.5GbE Network Jack
2 x Type-A USB 3.1 Gen2 Port
1 x HDMI
1 (PCIe3.0 x2) xM.2 2280 NVMe Slot
System Fan:80 mm x 80 mm x25mm 3 pcs
Fan Mode:Smart, High speed, Middle speed, Low speed
Noise Level:31.2dB(A) (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in idle state)
Power Supply:250W
AC Input Voltage:100V - 240V AC
Current Frequency:50/60 Hz, single frequency
Power Consumption:
72W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in read/write state)
29W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in hibernation)
